CONVEYOR BELT NOVBELT 400 HC
Inquiry Now
Description
conveyor belt
Application of the conveyor belt NOVBELT NN/17ER40 S=CPLUS
• Metalworking, mechanical engineering and the automotive industry: transport of sheet roll or single materials, assembly lines; transport of raw (unvulcanized) rubber compounds in hot / cold form (calendared or in dolls).
• Postal and logistics terminals, baggage transport systems at airports and railway stations.
• Packaging lines, cardboard lines; transportation of parts and housings of household appliances.
• Automatic slitting lines.
Distinctive features and advantages of the NN/17ER40 S=CPLUS
conveyor belt
• Resistance to wear, cut, heat resistance; non-soiling surface, semi-rigid under pressure.
TECHNICAL DATA
| BELT THICKNESS: | 4.00 mm | 0.013" |
| PULLEY DIAMETER (MIN.): | 70 mm | " |
| PULLEY DIAMETER (MIN.) BACK FLEXING: | mm | " |
| BELT WEIGHT: | kg/m² | lb/ft² |
| PRODUCTION WIDTH: | mm | 78" |
| BREAKING STRENGTH: | ||
| TENSION FOR 1% ELONGATION: | 10 N/mm | |
| MAX. ADMISSABLE BELT TENSION (EQUAL TO 1.8% STRETCH): | ||
| OPERATING TEMPERATURE: | -10° to 120° C | ° to ° F |
BELT CONSTRUCTION
| TOP COVER MATERIAL: | NBR Impregnated Polyester |
| SURFACE FINISH: | Non-Woven |
| PROPERTY: | |
| COLOR: | Black |
| BOTTOM COVER MATERIAL: | Non-Woven Impregnated Polyester |
| SURFACE FINISH: | |
| COLOR: | Black |
